QSFP28 100G (LAN-WDM) LR4 Optical Transceiver
100G Ethernet / 100G telecom / InfiniBand
Model:JFTSM-QSFP28-100GLR4L
Share:
Purchase consultation
Product Specification
Data Sheets
Related Recommendation
DESCRIPTION

JFOPT’s QSFP28 100G (LAN-WDM) LR4 optical transceiver module is developed and produced based on the 100G Ethernet IEEE 802.3bm. The transmitter of QSFP28 module converts 4 lanes of 25Gb/s electrical signals into 4 LAN-WDM optical signals, and multiplexes them into 1 fiber to achieve 100Gb/s transmittion. At the receiving end, the module demultiplexes the 100Gb/s optical signal into 4 lanes LAN-WDM optical signals through a demultiplexer (DEMUX), and then converts them into 4 25Gb/s electrical signals.The center wavelength of the 4 LAN WDM channels are 1295.56, 1300.05, 1304.58 and 1309.14 nm. The 100G links is up to 10KM.

APPLICATION
100GBASE-LR4
InfiniBand QDR and DDR interconnection
100G Telecom
FEATURES
Hot pluggable QSFP28 form factor
Supports 103Gbps aggregate bit rates
Duplex LC receptacle optical interface compliant
All-metal housing for superior EMI performance
4x25.78Gbps LAN-WDM transmitter and High-sensitivity PIN-TIA receiver
Up to 10km on SMF
STANDARDS COMPLIANCE
Compliant with QSFP28 MSA
Compliant with SFF -8636
Compatible with IEEE802.3bm
RoHS6 compliant (lead free)
TEMPERATURE CHARACTERISTICS
ELECTRICAL CHARACTERISTICS




OPTICAL PARAMETERS
PRODUCTS DISPLAY




COMPATIBILITY
