News

Learn more about JFOPT from the latest news.

News

Quality Management

About the mysteries of MPO fiber patch cords, how much have you mastered? MPO fiber patch cords, with the advantages of multi-core, small size, and high transmission rates, play an important role in the field of optical communication, especially suitable for meeting the high-density cabling requirements of data centers. Now, let's comprehensively and systematically introduce the relevant knowledge of MPO.

How to choose data center-grade LC-LC fiber optic patch cords? Fiber optic patch cords play an important role in data center network wiring systems, with different interface types and transmission distances suitable for different scenarios. Taking data center-grade LC-LC fiber optic patch cords as an example, this article analyzes the methods and scenarios for selecting appropriate patch cords.

What are the differences between multimode fibers OM1, OM2, OM3, OM4, and OM5? Multimode fiber is a type of optical fiber used for short-distance transmission, widely utilized in scenarios such as campus networks, enterprise LANs, and data centers. Common types of multimode fibers available in the market include OM1, OM2, OM3, OM4, and OM5, each offering different data transmission capabilities.

How is LC Uniboot different from regular LC fiber connectors? A standard LC duplex connector typically consists of two LC simplex connectors joined together with a clip, with each connector containing a single fiber. In contrast, an LC Uniboot connector is an enhanced version of the LC duplex connector where two fibers coexist within a single 2.4mm or 3.0mm jacket, achieving the functionality of dual fibers in one cable. This greatly reduces the space requirements for cabling. Therefore, the main difference between an LC Uniboot connector and a regular LC fiber connector lies in its adoption of a single-cable dual-fiber design, thereby reducing the space requirements for cabling.

What are the basic points to consider when selecting fiber optic patch cords? Fiber optic patch cords are used as jumper cables in fiber optic cabling systems, connecting equipment to the fiber optic distribution network. They feature a thick protective layer and are commonly employed for connections between optical terminals and terminal boxes. These patch cords find applications in various fields including fiber optic communication systems, fiber optic access networks, fiber optic data transmission, and local area networks (LANs).

Extensive Applications of High-Speed, Low-Power 100G Optical Modules With the rapid development of the Internet, the demand for data transmission continues to grow. To meet this demand, optical communication technology is continuously developing and improving. Among them, 100G optical modules, as important communication equipment, have unique characteristics. This article will analyze the characteristics of 100G optical modules in detail.

Understanding the key points of MPO fiber optic patch cord interface modules? An MPO interface optical module refers to an optical module with an interface type of MPO, which needs to be used in conjunction with MPO interface patch cords. The MPO interface consists of male and female connectors and must be used in pairs. Typically, the interface of the optical module is of the MPO male connector type, hence requiring the use of MPO female patch cords to connect to the optical module.

How much do you know about fiber optic terminal boxes? Fiber optic terminal box is a device used for the termination of fiber optic cables, providing protection for the cable ends. As a crucial component of fiber optic systems, it is primarily used for branching, splicing, distribution, and protection of fiber cables. There are various types of fiber optic terminal boxes, including wall-mounted, desktop, and rack-mounted forms. They play an essential role in optical communication systems, ensuring secure connections and effective management of fiber cable ends.

Introduction to MPO Fiber Distribution Boxes MPO fiber distribution boxes are specifically designed devices for connecting multiple fibers, primarily used in high-speed network environments. As a type of fiber connector, MPO features multiple fiber ports, allowing multiple fibers to be connected to the same device.
